Smart+ Speed
The most powerful SPEED measurement Smart Camera.
- Applications: Speed Enforcement
The application fields of this camera are Instant Speed Enforcement and Average Speed Enforcement.
Smart+ Speed is the new enforcement camera designed to revolutionize road safety by accurately detecting and penalizing speeding violations.
With its top algorithms and on-edge processing power, this AI camera takes enforcement and security to a whole new level, setting new industry standards for accuracy, reliability, and efficiency.
Powerful on-edge AI camera designed for Speed measurement
Smart+ Speed camera – an on-edge AI camera that is specifically designed for speed measurement. This powerful camera is Powered by the Stark Neural plate & vehicle detector algorithm, Smart+ Speed swiftly and accurately identifies various vehicle types, from cars to trucks and motorcycles.
A new and innovative feature of the Smart+ Speed camera is its advanced plug&play POE Radar connection, which is fully adjustable. This allows for versatile deployment scenarios, as the camera can be installed at different angles to adapt to different installation layouts.
Smart+ Speed can cover up to 3 lanes in front and rear reading installations, managing vehicles in the same and opposite directions. Smart+ Speed offers excellent installation flexibility.
All transit plates are detected and available for:
- Speed enforcement (spot/average)
- Tax and insurance control
- Vehicle tracking
- Traffic monitoring
Applications
- Enforcement
- Traffic monitoring
- Security
Tattile brings to the next level the speed enforcement analysis with the new Smart+ Speed camera.
With its new Tattile Smart+ Speed camera system, Tattile takes enforcement and security to a whole new level, setting new industry standards for accuracy, reliability, and efficiency on the market for speed enforcement.
Smart+ Speed takes advantage of Stark’s new secure-by-design software architecture, offering a fully parametrizable and modular platform with a user-friendly web interface in multiple languages.
Tattile Smart+ Speed system works with a multi-tracking radar that continuously monitors up to three traffic lanes at a maximum width of 10.5 meters (34 feet) and identifies the speed and position of objects in the monitored area at a speed of up to 320 km/h (198 mph).
The external radar is connected to the camera using a plug-and-play POE connection. This configuration offers an easy installation procedure and adaptability to various installation environments. With the flexibility to adjust to different angles, it seamlessly integrates into diverse scenarios, ensuring optimal performance and coverage. Whether mounted on highways or urban streets, the adjustable external radar provides the versatility needed to enhance monitoring capabilities and enforce road safety measures effectively.
Smart+ Speed detects all transit with 99% of accuracy, providing complete recognition of brand, model, class, and color of the vehicle.
If a vehicle exceeds the speed limit, the object and transit detector combine their information with the radar track to capture an image of the vehicle and its license plate. The system collects relevant information such as the date, time, license plate number, and country along with the actual speed of the vehicle. All infarctions come with a monochrome picture of the license plate and a monochrome or color contextual image of the vehicle. The automatic number plate recognition technology embedded in the system does not require any time-consuming post-processing. All speed violation evidences can directly be addressed to the authorities in real-time or stored on board.
Tattile Smart+ Speed camera is the perfect solution for law enforcement agencies and public safety organizations looking to enhance their speed enforcement efforts while also improving public safety on the roads.
Overall, the Smart+ Speed camera is an excellent choice for anyone looking for a reliable and efficient speed measurement solution
| SMART+ SPEED | |
|---|---|
| SOFTWARE FEATURES AND PERFORMANCE | |
| Software platform | Stark |
| AI hw accelerator | Up to 2 hardware accelerators |
| Lane Detected | Up to 3 lanes |
| Max Vehicle Speed | Up to 320 km/h – 198 mph depending on layout |
| Working Distance | Up to 40m – 115 ft |
| Detection | >99.5% |
| Reading | Up to 98% |
| OCR | Up to 3 ANPR (ALPR) engines on board |
| Third party OCR | Optional |
| Classification | Optional |
| Vehicle Color | Optional |
| Vehicle Maker | Optional |
| Vehicle Model | Optional |
| Video Streaming | Color video streaming via standard RTSP protocol |
| AES256 | Yes |
| SHA2 | Yes |
| Image Compression | JPG |
| Streaming Profile | H.264, H.265 |
| CONFIGURATION | |
| Web Server | Installation and configuration with on board Web Application |
| Integration | Support for HTTP REST API |
| Date and Hour | Synchronization via NTP protocol or GPS |
| Software Update | Upgrading via Web Application and integration protocols |
| DATA TRANSMISSION | |
| Output Action Types | HTTP, HTTPS, FTP, SFTP, TCP RAW, Serial Communication, Local Storage |
| Message formats | Fully customizable message formats including JSON, XML, custom string |
| Configuration | Configurable events/actions and metadata |
| Serial Port | Yes, RS485 full duplex |
| Digital output event | Yes |
| FTP Server | Yes, access to storage partition |
| OPERATING MODE | |
| Autotrigger | Self-triggering based on AI image analysis on multiple lanes, even without plates |
| Trigger mode | Image capture and processing triggered by Ethernet or digital signal |
| SYSTEM | |
| ANPR (ALPR) camera | 8 Megapixels Grayscale |
| Context Camera | 5 Megapixels Color |
| Illuminator | 12 high power LEDs, infrared @ 850 nm |
| Lenses | Fixed lens configuration |
| Operating System | Linux Operating System |
| Custom software | Optional, with Linux container |
| Digital I/O | 1 Optoisolated input – 1 Relay Output – 2 Strobe output |
| IP Protection | IP68 |
| Ethernet | GigaBit Ethernet 10/100/1000 |
| Storage | uSD up to 128 GB |
| Internal SSD | Optional up to 1TB |
| GPS | Yes |
| LTE | Optional |
| WiFi | Yes |
| PSE | Yes |
| TECHNICAL DATA | |
| Operating & Storage Temperature | From -40° to +60° C – From -40° to +140° F |
| Operating & Storage Humidity | Up to 95% non-condensing |
| Dimensions | 290 x 323 x 235 mm – 11.4 x 12.7 x 9.3 in (including antenna and speed sensor) |
| Weight | 8.1 kg – 17.9lbs |
| Power supply voltage | 24 Vdc |
| Power consumption (typical) | 47W (standard config), 57W (full config) |
| Power consumption (maximum) | 95W |
| F02363-000 | SMART SPEED 85 |
In order to update the firmware, please open a ticket on the Tattile Academy platform, selecting “FW upgrade” in the request type field.
